Low-friction UHMW film tape for demanding sliding, wear and impact applications.
UHMW Anti-Friction Film Tape combines an ultra-high-molecular-weight polyolefin backing with a pressure-sensitive acrylic adhesive. Its exceptionally low coefficient of friction helps materials slide smoothly without sticking, while its chemical, abrasion, impact and shock resistance make it a durable engineering tape for industrial and mechanical use.
- Reduces friction and wear: creates a slick, durable surface on guides, rails, chutes and sliding components.
- Industrial durability: resists abrasion, chemicals, impact and shock.
- Broad application range: suited to conveyors, bearings, hopper liners, dead plates, wear pads, automotive components and furniture or drawer slides.
- Natural transparent film: maintains a clean, unobtrusive appearance.
- Pressure-sensitive acrylic adhesive: provides secure, consistent bonding.
Easy three-step selection
- Select the film thickness: 3, 5, 10, 15 or 20 mil.
- Select the width: 1/2, 3/4, 1, 1.5, 2, 3 or 4 inches.
- Select Individual Roll or Full Case.
Individual options include free standard shipping to eligible U.S. addresses; availability is confirmed at checkout. Full-case shipping is paid separately by the buyer and is not included in the case price.
Widths and full-case quantities
| Width | Rolls per case |
|---|---|
| 1/2 inch (12.5 mm) | 72 |
| 3/4 inch (19 mm) | 48 |
| 1 inch (25 mm) | 36 |
| 1.5 inch (38 mm) | 24 |
| 2 inch (50 mm) | 18 |
| 3 inch (75 mm) | 16 |
| 4 inch (100 mm) | 12 |
Lengths and release liners
- 3, 5 and 10 mil: 36 yd (33 m), 108 ft per roll; 3 mil white paper liner.
- 15 and 20 mil: 18 yd (16.5 m), 54 ft per roll; 2 mil blue poly liner.
- Core: 3-inch plastic core.
Buy 5 or more full cases and save 10%
Order five or more full cases and receive 10% off automatically at checkout. Eligible thicknesses and widths can be combined to reach five cases. The discount applies only to full-case variants; shipping is charged separately.
Performance by thickness
| Film | Total tape | Peel adhesion | Tensile | Elongation | Max temperature |
|---|---|---|---|---|---|
| 3 mil | 5 mil | 50 oz/in | 20 lb/in | 300% | 225°F |
| 5 mil | 7 mil | 50 oz/in | 40 lb/in | 350% | 225°F |
| 10 mil | 12 mil | 50 oz/in | 80 lb/in | 425% | 225°F |
| 15 mil | 17 mil | 60 oz/in | 60 lb/in | 300% | 200°F |
| 20 mil | 22 mil | 60 oz/in | 60 lb/in | 300% | 200°F |
Before you order
Distinguish film thickness from total tape thickness. Match wear, clearance, temperature, and sliding-load conditions before selection.
Compare a related option: Low Density PVC Foam Tape – SF-VFLD (Full Case).
Ask Total Tapes about this product with the selected size, application, and quantity.
Distributor and business orders
For case quantities, repeat purchasing, or resale requirements, request a business quote. Include the product name, selected size or model, required units or cases, expected reorder frequency, delivery ZIP code, and needed-by date. Product availability and any quoted terms are confirmed for your order.
